Description
Description:
Rebuilt Industrial battery
Rebuilt Brush motors
New Brooms
New Flaps
New Filters
New Paint Decals
90 days parts warranty
Fully Serviced and Reliable
The battery-powered Tennant 8300 introduces patented sweeping technology combined with legendary scrubbing productivity to set a new standard for tennant sweeper scrubbers. Experience MTS™ Sweeping Engineered with the new Multi-Technology Sweeping (MTS™) system, the tennant 8300 deploys a 10 inch/250 mm dia. brush with an 8 inch 205 mm dia. re-directional cylinder to sweep debris into the hopper without brush carry-over. From crushed popcorn boxes to sand, bolts and nails, debris is swept in advance of scrubbing. TufGuard™ side brushes increase the sweeping path to 64 inches/1630 mm, making the Tennant 8300’s productivity unmatched in its class. Super-Size Hopper Capacity The MTS system uses the entire hopper space by sweeping debris to the front of the hopper. In fact, the smaller 8300 hopper holds 300 lb/136 kg of debris, providing plenty of capacity while reducing overall machine length. It’s also a “smart-hopper,” with a microprocessor keeping it level as it dumps up to 5 ft/1530 mm. Rotating 160 degrees, the Hopper then “senses” position on the way down, locking back into place. Legendary Tennant Productivity With a 57 gallon/216 L solution tank and a 74 gallon/280 L recovery tank, the Tennant 8300’s scrubbing capacity matches its generous sweeping capacity. Hard on dirt and grime, the Tennant 8300 is easy on the operator. Power steering is standard, along with one-button scrubbing, on-board diagnostics, and a LCD system. No-tool brush, squeegee and filter changes make maintenance a snap. The Tennant Model 8300 sweeper-scrubber: exceeding all expectations and redefining cleaning excellence for years to come.
SWEEPING SYSTEM
Cleaning Path
Single Side Brush (RH Side) 50 in 1270 mm
Dual Side Brush 64 in 1630 mm
Main Brush Length 36 in 920 mm
Brush Motor .8 hp 0.60 kW
Side Brush diameter 19 in 490 mm
Hopper Volume Capacity 3 ft
3 85 L
Hopper Weight Capacity 300 lb 136 kg
Hopper Dump Height 60 in 1530 mm
SCRUBBING SYSTEM
Cleaning Path
MaxPro™ 1000 Scrubhead (standard) 40 in 1020 mm
MaxPro™ 1200 Scrubhead (optional) 48 in 1220 mm
Edge Scrub Reach 5 in 130 mm
Solution Tank 57 gal 216 L
Demisting Chamber 17 gal 64 L
Solution Recycling Tank (ES
™ Option) 90 gal 340 L
Disk Scrubhead
Brush Speed 320 rpm 320 rpm
Brush Down Pressure (variable to) 500 lb 227 kg
Brush Size (2) MP1000 diameter 20 in 510 mm
Brush Motor (2)MP1000 and (3)MP1200 1 hp 0.75 kW
Brush Size (3) MP1200 diameter 16 in 410 mm
Cylindrical Scrubhead
Brush Speed 500 rpm 500 rpm
Brush Down Pressure (variable to) 500 lb 227 kg
Brush Size (2) diameter 9 in 230 mm
Brush Motor (2) 1.5 hp 1.1 kW
RECOVERY SYSTEM
Recovery Tank 74 gal 280 L
Vacuum Fan Speed 14,000 rpm (each of 2)
Vacuum Water Lift 65 in 1650 mmVacuum Fans (2) .85 hp 0.63 kW
PROPELLING SYSTEM
Propel Speed Forward (variable to) 5.5 mph 8.0 km/h
Propel Speed Reverse (variable to) 3.0 mph 4.8 km/h
Propel Motor 4.6 hp 3.4 kW
Gradeability
Transport at Gross Weight 8°/14% 8°14%
Working (Sweeping/Scrubbing) 6°/10.5% 6°/10.5%
Ground Clearance (Transport) 2 in 50 mm
Tires Front (1), Solid 6 in x 16.25 in 150 mm x 410 mm
Tire Rear (2), Solid 5.0 in x 16 in 130 mm x 410 mm
