Description
This is the low-profile member of the 115Ah family. The Leoch LDC12-115-G31-T uses T11 (M8) terminals that sit close to the case, which keeps the overall height at 8.66 inches and the weight at 69.2 lbs. Rated capacity is 115Ah at 20 hours, 95Ah at 5 hours and 85Ah at 3 hours, with reserve capacity of 239 minutes at 25A, 80 minutes at 56A and 52 minutes at 75A.
Next to the LDC12-105-G27 models, it adds 10Ah at 20 hours and 7Ah at 5 hours. You pay for that in space and mass: the case is 24 mm longer and 5 mm wider, and about 9 lbs heavier, so a tray cut for the G27 size will not take it.
The DT-terminal twin of this battery is 17 mm taller. The datasheet gives the operating limits as -20 to 55°C for discharge, 0 to 40°C for charge and -15 to 40°C for storage, which covers most indoor cleaning duty, and the case is ABS.
Specifications
| Model | LDC12-115-G31-T |
| Voltage | 12V |
| Capacity @ 20hr | 115Ah |
| Capacity @ 5hr | 95Ah |
| Capacity @ 3hr | 85Ah |
| Reserve Capacity | 239 / 80 / 52 min (25A / 56A / 75A) |
| Length | 12.99in (330mm) |
| Width | 6.81in (173mm) |
| Container Height | 8.35in (212mm) |
| Height over Terminals | 8.66in (220mm) |
| Weight | 69.2 lbs (31.4kg) |
| Terminal | T11 (M8) |
| Case Material | ABS |
| Operating Temperature | Discharge -20 to 55°C, charge 0 to 40°C, storage -15 to 40°C |
