Description
The Leoch LDC12-105-G27-T is a 12V 105Ah AGM battery in Leoch's Group 27 case with a single top-terminal design, giving you the same capacity as our dual-terminal LDC12-105-G27-DT in a simpler bolt-in configuration. It's a solid choice for sweepers, scrubbers, and small electric vehicles where a single set of terminals is all your wiring harness needs.
Every LDC-series battery shares Leoch's deep-cycle AGM foundation: premium virgin lead plates, a heavy-duty grid/paste design engineered for repeated full-depth discharges, and a sealed, valve-regulated case that never needs watering. The double separator layout keeps the plates compressed and wet, extending cycle life and improving resistance to vibration in mobile equipment.
Why choose the LDC12-105-G27-T
- 105Ah capacity in the widely-compatible Group 27 case size
- Single top-terminal layout simplifies wiring on equipment that doesn't need dual posts
- Maintenance-free, non-spillable AGM chemistry safe for enclosed compartments
- Consistent Leoch manufacturing quality across the full LDC lineup
Specifications
| Model | LDC12-105-G27-T |
| Voltage | 12V |
| Capacity (20HR) | 105Ah |
| Capacity (5HR) | 88Ah |
| Capacity (3HR) | 78Ah |
| Length | 306mm (12.05in) |
| Width | 168mm (6.61in) |
| Height | 208mm (8.19in) |
| Total Height (with terminals) | 214mm (8.43in) |
| Weight | 27.3kg (60.2 lbs) |
| Terminal | Single Top Terminal (T) |
| Case Material | ABS/PP |
| Battery Type | Sealed AGM, Valve-Regulated |
Backed by Leoch's standard limited warranty. If you're unsure whether the single-terminal (T) or dual-terminal (DT) version fits your existing wiring, contact us before ordering.
