Description
The J305-AES is the 6V sealed AGM equivalent of the flooded J305H-AC, meant for equipment wired for multiple 6V cells in series rather than a single 12V unit. It's one of the broader-application AES batteries — Trojan lists marine, RV, floor cleaning, and aerial work platform use all under the same SKU, so it's a reasonable stocking choice if a fleet mixes equipment types that all happen to need a 6V AGM cell.
Capacity is 228Ah (5-hr) up to 320Ah at the 100-hour rate, with 603 minutes of reserve at 25 amps — meaningfully more total energy than the 12V options on this list, at the cost of needing more batteries wired together to reach a given pack voltage.
- 6V, 228Ah (5-hr rate) / 320Ah (100-hr rate)
- Dimensions: 11.66" L x 6.94" W x 14.09" H
- Weight: 95 lbs
- Terminals: automotive post & stud (DT), M8 insert, M8 with LT adapter
- Sealed, non-spillable; 3-year warranty
