Description
The US 12VE XC2 is a 12-volt, 145Ah flooded lead-acid battery in U.S. Battery's compact GC12 case — the entry point of the 12-volt lineup for equipment that only has room for a single battery.
Where our 6-volt models are typically wired in banks of two or more, the 12VE runs solo, so its plate design is tuned to get the most out of that single-battery footprint rather than chase raw capacity. It's assembled by hand at U.S. Battery's Corona, California plant.
Why choose the US 12VE XC2
- 145Ah in a GC12 case sized for single-battery compartments
- Molded-in UTL terminal — no adapter needed on most equipment
- A lighter, lower-cost starting point before stepping up to the 12VRX
- Built on U.S. Battery's Xtreme Capacity 2 plate construction
Specifications
| Model | US 12VE XC2 |
| Voltage | 12V |
| Capacity (20HR) | 145Ah |
| Minutes @75A | 62 |
| Minutes @25A | 270 |
| Length | 13.125" |
| Width | 7.0625" |
| Height | 11.375" (w/o handles) |
| Weight | 63 lbs |
| Terminal | Molded-in UTL |
| Case Material | Polypropylene, heat sealed |
| Battery Type | Flooded Lead Acid (FLA) |
Confirm compartment dimensions before ordering — the GC12 footprint is narrower and taller than the GC2 case used on our 6-volt models.
